AJAX CHISELS AND PUNCHES SHOULD NEVER BE STRUCK AGAINST SURFACES THAT ARE HARDER THAN THE TOOLS THEMSELVES; I.E., “BEARINGS” AND “BEARING RACES” HAVE A MUCH HIGHER HARDNESS THAN THE OPTIMUM HARDNESS OF THE WORKING END OF ALL CHISELS AND PUNCHES. THERE ARE SPECIFIC AND SAFER PROCEDURES FOR THE REMOVAL OF THESE TYPES OF ITEMS. FOLLOW CERTIFIED MECHANIC’S RESOURCES FOR CORRECT APPLICATION OF TOOLS OR CALL AJAX TOOLS FOR ASSISTANCE.
All Ajax Rescue tools need to be used with care and you need to follow all safety precautions that are listed by the manufacturer and all safety procedures deemed necessary by your place of employment. These safety procedures will include but are not limited to wearing proper safety apparel, wearing safety goggles, and using all tools in the way that they were intended to be used. Ajax Rescue Tools asks all users of our products to follow all safety precautions and to use our tools with care.
CHISEL APPLICATIONS BY CHISEL TYPE:
CHISEL TYPE: DOUBLE BLADED PANEL CUTTER
a) Cutting sheet metal i.e. roofs and body panels on automobiles, vans, trucks, buses and trailers.
b) Cutting sheet metal i.e. buildings, overhead and factory doors.
CHISEL TYPE: KWIK CUTTER
a) Cutting A, B, C, posts on automobiles, vans, and trucks.
b) Cutting door hinges on automobiles, vans, trucks and factory doors.
c) Cutting around nadir pin mounting brackets
d) Cutting sheet metal on motor coaches, school buses and mobile home trailers.
CHISEL TYPE: MOIL POINT
a) Chipping: concrete, cinder block and masonry brick.
CHISEL TYPE: NARROW FLAT CHISEL
a) Cutting bolts, nuts, etc.
b) Chipping concrete, cinder block and masonry brick.
CHISEL TYPE: WIDE FLAT CHISEL
a) Cutting metal, bolts, and nuts.
b) Chipping concrete, cinder block and masonry brick.
CHISEL TYPE: CLAY SPADE/SHOVEL
a) Digging in clay, dirt, gravel, etc.
Each Ajax Rescue Kit features an air hammer specially selected for its durability and dependability. Every Rescue Kit includes an Ajax Kwik Change Retainer. The Kwik Change Retainer was originally developed by Ajax to hold the cutting tool securely in place, yet allowing the technician to change tools in a matter of seconds during emergency procedures. The Kwik Change Retainer also allows the technician the use of Ajax Exclusive Non-turn chisel bits. These Non-turn bits can be indexed into different positions to allow one-hand operation of the hammer when necessary. The Ajax Kwik Change Retainer is the only retainer that lets you use both Turn type and Non-turn type chisel bits. The Ajax Rescue Tools high-pressure regulator has a universal design which allows the technician to use either 2216 psi or 4500 psi air tanks without having to change the regulator. This regulator is rated at an operating pressure up to 300 psi, which is well above the recommended operating pressure of most air tools. Normal body metals, such as, A, B and C posts, quarter panels and firewalls require only 90 psi. However, heavier metals, such as Nader pins, door hinges, etc., may require 150-160 psi. A safety blow-off valve prevents the technician from exceeding the maximum pressure capacity level. This regulator lets you operate the tool at the proper air pressure essential for the most efficient operation while allowing you to use extra air power when needed. This allows the rescue technician to adjust to a higher operating pressure when attempting to cut through heavier steel, and complete a successful rescue or extrication..
